400W LED Flood Light High Power Light 350W 300W LED Tunnel Light

400W LED Flood Light High Power Light 350W 300W LED Tunnel Light

1.Parameter 2.Features a) ·Replace 700W metal halide lamp b)·Good junction temperature & insulation c)·High output and e

Send your inquiry

DESCRIPTION

Basic Info
Model NO. JYT11-400E
Input Voltage 90-305V
LED Chips Brand Bridgelux
Transport Package Carton
Origin Ningbo
Product Description

1.Parameter

1

Model

JYT11-400E

2

Input voltage

AC90-305V 50/60HZ

3

power

500W

4

Driver efficiency

≥90%

5

Power factor

≥0.95

6

LED quantity

112pcs(5 modules)

7

LED type

5050

8

Luminous efficiency

130-170lm/W

9

Color temperature

5700K

10

CRI

70 ≥

11

Beam angle

40°

12

Ts

≤40ºC

13

Operation temperature

-30ºC~+45ºC,10%~90%RH

14

Storage temperature

-30ºC~50ºC

15

LED life

>50,000h

16

housing material

6063-T5 AL + PC

17

SIZE(mm)

335*422*379

18

Carton size (mm)

340*440*165

19

IP

IP66

20

Wind resistance level

Level 14 (42m/s)

21

IK

≥IK09

22

Warranty

5 years

23

Driver

Inconvenient/meanwell

2.Features

a) ·Replace 700W metal halide lamp

b)·Good junction temperature & insulation

c)·High output and excellent thermal

d)·Light weight and attractive appearance

e)·Universal voltage 100~305Vac

f)·50,000 hours rated average life

3.Dimension

400W LED Flood Light High Power Light 350W 300W LED Tunnel Light

400W LED Flood Light High Power Light 350W 300W LED Tunnel Light


4.Application

·Area Lighting·Architecture Lighting·Stadium Lighting·Light Tower
